NUX B8 2.4Ghz Pedalboard Wireless System - Digital B-8 Gitar Bass

NUX B-8 is a redefined wireless system with automatic setup, 2.4 GHz interference-free broadcasting frequency, and 24-bit 48 kHz high-quality audio transmitting. The signal transmitting latency is as low as 2.5ms at the best performance. The operation range is up to 50 meters (160-feet)

Specifications

Operating Frequency Band

2400-2483.5MHz

Audio Quality

24bit/48kHz

Frequency Response

20Hz-20kHz

Latency

2.5ms(best performance setting)-8.7ms(safety mode)

Input Impedance

1 MΩ

Maximum Input Level

1 kHz at 1% THD +6.2 dBV (5.78 Vp-p)

THD+N

0.01% 1kHz, typical

Dynamic Range

122dB, A-weighted(OUTPUT/SEND)

Output level Adjustment Range

mute -64dB~0dB

Auto-sleep Mode

N/A

Built-in Battery Capacity

3.7V/500mAh Rechargeable Li-polymer (Transmitter)

TX Battery Life

up to 6.5 hours

Power Requirements

7V to 12V DC, 500mA min, negative tip power supplies(Receiver)

Operation Range

Up to 50 m (165 feet) maximum

TX dimesions

72.5mm*49.3mm*23mm (L*W*H)

TX weight

63g

RX dimensions

122*95*60mm (L*W*H)

RX weight

500g
